SupaPlumb Round Bar Valve Shower Fitting Kit
Professional-Grade Support System for Bar Mixer Showers
Core Features
✔ Universal Mounting Solution – Converts any bar mixer to wall-mounted installation
✔ Structural Support – Eliminates need for in-wall reinforcement
✔ Premium Components – Chrome-plated brass adapters with corrosion-resistant hardware
✔ Complete Installation Kit – Includes all necessary fittings for immediate installation
✔ 5-Year Manufacturer Guarantee – Backed by SupaPlumb quality assurance
Technical Specifications
| Component | Specification |
|---|---|
| Material | Chrome-plated brass adapters |
| Thread Size | Standard 1/2″ BSP |
| Max Load Capacity | 15kg vertical load |
| Wall Compatibility | Solid & stud walls (plugs included) |
| Finish | Brushed chrome (EN 248 compliant) |
| Kit Weight | 100g (boxed) |
Included Components
-
2× Chrome Threaded Adapters (1/2″ BSP male-female)
-
2× Adjustable Screw Plates (30mm adjustment range)
-
2× Wall Plates (50mm diameter)
-
4× High-Grip Wall Plugs (suitable for 8-12mm walls)
-
4× Stainless Steel Screws (M5×40mm)
-
2× Compression Olives (15mm copper pipe)
Key Benefits
① Structural Integrity
-
Distributes weight load across wall surface
-
Prevents pipe stress from shower use
② Universal Compatibility
-
Works with all standard bar mixers
-
Suitable for 10-15mm bar diameters
③ Time-Saving Installation
-
No wall chasing required
-
Complete fitting solution in one pack
④ Professional Finish
-
Concealed mounting system
-
Chrome matches premium mixer finishes
Installation Guide
-
Mark Position
-
Locate studs/solid wall area
-
Ensure 150mm center alignment
-
-
Secure Wall Plates
-
Use included plugs/screws
-
Verify level installation
-
-
Attach Adapters
-
Thread onto mixer valve tails
-
Hand-tighten plus ¼ turn with spanner
-
-
Mount Bar
-
Slide through adjustable plates
-
Tighten grub screws evenly
-
Installation time: ≤15 minutes for professionals
Maintenance Requirements
◉ Annual torque check on all fittings
◉ Inspect wall anchors every 2 years
◉ Clean chrome surfaces with pH-neutral cleaner
Warranty Coverage
✓ Adapter thread integrity
✓ Chrome plating durability
✓ Hardware corrosion resistance
Excludes improper installation damage
Frequently Asked Questions
Q: Suitable for tiled walls?
A: Yes – includes masonry drill bits for tile penetration
Q: Minimum wall thickness?
A: 80mm solid or 12mm stud with reinforcement
Q: Compatible with rain showers?
A: Yes – rated for standard overhead shower weights
Q: Additional anchors available?
A: Yes – SP-ANCH5 heavy-duty anchors sold separately
Compliance Marks:
✓ EN 248 (Surface durability)
✓ WRAS approved materials
Ideal For:
-
Bathroom renovations
-
New build installations
-
Bar mixer upgrades
Product Code: SP-BARKIT100
Note: Professional installation recommended for warranty validation
