SupaPlumb Jura Bath Shower Mixer Tap
The SupaPlumb Jura Bath Shower Mixer Tap represents the pinnacle of bathroom mixer tap engineering, combining elegant aesthetics with superior functionality. This professional-grade fitting offers both bath filling and showering capabilities through a single, high-performance unit designed for residential and light commercial applications.
Technical Specifications
Core Dimensions & Physical Properties
| Measurement | Specification |
|---|---|
| Overall Height | 140mm |
| Projection Depth | 73mm |
| Spout Length | 120mm |
| Shower Head Diameter | 100mm |
| Weight (Boxed) | 1.5kg |
| Material Composition | CW617N Lead-Free Brass (Body) |
| Finish | Chrome Plating (Class 4, EN 248) |
Performance Metrics
| Parameter | Value |
|---|---|
| Minimum Operating Pressure | 0.5 bar |
| Maximum Operating Pressure | 6 bar |
| Optimal Pressure Range | 2-3 bar |
| Flow Rate @ 1 bar | 12.5 l/min |
| Temperature Range | 5-65°C |
| Valve Cycles | 500,000+ |
Construction & Materials
Premium Components
-
Main Body
-
Solid brass construction (CW617N grade)
-
25µm chrome plating thickness
-
Salt spray tested (96 hours, ASTM B117)
-
-
Ceramic Disc Cartridge
-
35mm diameter ceramic discs
-
90° operation range
-
Self-cleaning design
-
-
Shower System
-
Chrome-plated ABS shower head
-
3-zone spray pattern
-
Anti-kink stainless steel hose (1.5m length)
-
Included Components
Complete Installation Kit
-
Main Unit
-
Bath/shower mixer valve
-
Integrated diverter mechanism
-
-
Fittings & Hardware
-
26mm (3/4″) compression connectors
-
Brass back nuts (x2)
-
EPDM rubber washers (x2)
-
Silicone mixer tap gasket
-
-
Shower Accessories
-
Chrome-plated wall bracket
-
1.5m stainless steel braided hose
-
Mounting screws and wall plugs
-
-
Documentation
-
Installation manual (multilingual)
-
Warranty registration card
-
Installation Requirements
Plumbing Specifications
| Requirement | Detail |
|---|---|
| Water Connections | 26mm (3/4″) BSP |
| Minimum Wall Clearance | 80mm |
| Recommended Pipework | 15mm or 22mm copper/PE-X |
| Mounting Surface | Flat, level bath rim |
Step-by-Step Installation Guide
-
Preparation
-
Isolate water supply
-
Verify bath thickness (3-40mm)
-
-
Main Unit Installation
-
Position mixer on bath rim
-
Secure with provided back nuts (torque to 12Nm)
-
Connect hot/cold supplies
-
-
Shower Assembly
-
Mount wall bracket at 1.8-2.0m height
-
Attach shower hose to mixer outlet
-
Connect shower head
-
-
Testing & Commissioning
-
Pressure test at 1.5× working pressure
-
Verify diverter operation
-
Check for leaks
-
Performance Features
Advanced Water Control
-
Precise Temperature Regulation
-
±2°C temperature stability
-
Thermostatic protection against scalding
-
-
Flow Optimization
-
Laminar flow spout design
-
Aerated shower stream
-
Durability Enhancements
-
Corrosion Protection
-
Triple-layer chrome plating
-
Internal dezincification resistance
-
-
Mechanical Reliability
-
Brass-to-brass moving parts
-
Reinforced hose connections
-
Maintenance Protocol
Scheduled Maintenance
| Interval | Task | Procedure |
|---|---|---|
| Weekly | Clean chrome surfaces | Microfiber cloth + pH-neutral cleaner |
| Monthly | Inspect hose/washers | Check for wear/kinks |
| Annually | Service cartridge | Lubricate with silicone grease |
| Biannually | Descale shower head | Citric acid soak (hard water areas) |
Warranty & Compliance
10-Year Guarantee Coverage
-
Included Components
-
Brass body and internal mechanisms
-
Chrome plating integrity
-
Ceramic disc cartridges
-
-
Exclusions
-
Hose and washers (consumables)
-
Damage from improper installation
-
Scale buildup in hard water areas
-
Certifications & Standards
-
Safety: EN 200, EN 248
-
Performance: WRAS approved
-
Environmental: RoHS compliant, WEEE registered
Commercial Applications
Project Specifications
-
Hotel/Gym Installations: Meets ADA clearance requirements
-
Healthcare Facilities: Optional antimicrobial coating available
-
Marine Environments: Optional 316 stainless steel hardware
Ordering Information
-
Packaging: Double-wall corrugated with foam inserts
-
Pallet Quantities: 36 units
-
Lead Time: 3-5 working days (UK mainland)
Technical Support
-
Engineering Drawings: Available in DWG/PDF format
-
Installation Videos: QR code access
-
Direct Support: Dedicated technical hotline
