SupaPlumb Eiger Bath Taps W: 50mm H: 84mm D: 129mm
The SupaPlumb Eiger Bath Taps combine elegant design with high-performance functionality, featuring a ¼ turn ceramic disc valve and solid brass construction for reliable operation in all water pressure systems.
Technical Specifications
| Measurement | Specification |
|---|---|
| Width (W) | 50mm |
| Height (H) | 84mm |
| Depth (D) | 129mm |
| Boxed Weight | 1.3kg |
| Material | CW617N Lead-Free Brass |
| Finish | Chrome Plating (Class 4, EN 248) |
| Valve Type | Ceramic Disc (¼ turn) |
| Flow Rate | 13.9 l/min @ 1 bar |
| Pressure Range | 0.5 – 6 bar |
| Optimal Pressure | 2 – 3 bar |
| Cartridge Model | TSC270 329444 Quick Closing |
| Connection Size | G3/4″ 20 Spline H55 |
Key Features
Premium Construction
✔ Solid Brass Body – Durable CW617N lead-free brass construction
✔ Ceramic Disc Valve – Smooth ¼ turn operation with 500,000+ cycle rating
✔ Chrome Plated Finish – 25µm thick coating, salt spray tested (96hrs)
Performance Advantages
✔ Universal Pressure Compatibility – Works from 0.5 to 6 bar
✔ High Flow Rate – 13.9 l/min at 1 bar for quick bath filling
✔ Quick-Closing Cartridge – TSC270 model for precise water control
Installation & Maintenance
✔ Easy Installation – Standard G3/4″ connections
✔ Low Maintenance – Self-cleaning ceramic discs
✔ 10 Year Guarantee – Manufacturer-backed assurance
Included Components
-
1 x SupaPlumb Eiger Bath Tap set
-
TSC270 329444 Quick Closing Cartridge
-
All necessary washers and fittings
-
Installation instructions
Installation Requirements
-
Water Connections: G3/4″ BSP
-
Recommended Tools: Adjustable spanner, thread seal tape
-
Professional Installation Recommended
Maintenance Guide
-
Clean with mild, non-abrasive cleaners
-
Avoid acidic cleaning products
-
Check washers annually
Why Choose Eiger Bath Taps?
-
Reliable Performance – Precision-engineered ceramic valve
-
Stylish Design – Sleek chrome finish
-
Long-Term Value – 10 year guarantee
Professional installation recommended for optimal performance and warranty validation
